Name: Hot Screw Conveyor for Powder Es Fire Resistant Conveyors 168 325 273 Carbon Steel Spiral Conveyor
Brand: Henan Hengyou Machinery Equipment Co., Ltd.
Availability: InStock

Home Products Screw Feeders

Hot Screw Conveyor for Powder Es Fire Resistant Conveyors 168 325 273 Carbon Steel Spiral Conveyor

Product Details:

Place of Origin:	Henan, China
Brand Name:	HENGYOU

Contact Now

Detailed Product Description

Applicable Industries:	Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C	Belt Material:	Stainless Steel
Dimension(LWH):	Customizable	Warranty:	3 Years
Special Feature:	Durable	Layer:	/
Material:	Stainless Steel, Carbon Steel	Speed:	Adjustable
Showroom Location:	None	Condition:	New
Warranty Of Core Components:	3 Years	Weight (KG):	150
Voltage:	220V/380V	Feature:	Adjustable
Material Feature:	Fire Resistant	Structure:	Belt Conveyor

Type	165	219	373	325	426
diameter of inner core	60	60	60	89	0-6m:108	6-13m:114
wall thickness	5	5	5	5	5
diameter of screw blade	140	190	240	290	390
blade pitch	140	190	230	290	390
thickness of screw blade	4mm	4mm	4mm	4mm	4mm
connecting screw end disc and reducer	12*30	12*45	12*45	12*45
connection flange	1652number	2192number	2732number	3252number	4262number
bearing	165	219	273	325	426
sleeves	2*number	2*number	2*number	2*number	2*number
U-joint	165	219	273	325	426
U-joint flange	219	273	273	325	426
size(customizable)	400*400	400*400	400*400	400*400	400*400
thickness of hopper)	2	2	2	2	2

Mobile Sugar Screw Conveyor is the main unit for mechanized transportation in all walks of life and departments, which can reduce the labor intensity of transportation work, improve work efficiency, and save labor.

Powder Screw Feeder Conveyor have a wide range of applications, suitable for all walks of life, such as building materials, chemicals, electric power, metallurgy, coal, machinery, light industry and grain industries, and suitable for the transportation of all granular, powder, and small pieces of materials.
