Name: High Efficiency Mini diesel Concrete Pump Diesel Concrete Trailer Pump with Remote Concrete Pump Construction Machinery
Brand: Henan Hengyou Machinery Equipment Co., Ltd.
Availability: InStock

Home Products Hot-selling product

High Efficiency Mini diesel Concrete Pump Diesel Concrete Trailer Pump with Remote Concrete Pump Construction Machinery

Product Details:

Place of Origin:	Henan, China
Brand Name:	HENGYOU

Contact Now

Detailed Product Description

Power Type:	Diesel	Weight:	5000 Kg
Dimension(LWH):	11055X2510X3830	Warranty:	1 Year
UNIQUE SELLING POINT:	High Operating Efficiency	Max. Vertical Conveying Distance:	200m
Max. Horizontal Conveying Distance:	400m	Productivity:	90m3/h
Machinery Test Report:	Provided	Video Outgoing-inspection:	Provided
Core Components:	Engine	Condition:	New
Showroom Location:	None	Marketing Type:	New Product 2020
Warranty Of Core Components:	1 Year	Applicable Industries:	Building Material Shops

item	value
Place of Origin	Henan China
Condition	New
Brand Name	HENGYOU
Marketing Type	New Product 2023
Product name	concrete pump
Power type	Electric Diesel
UNIQUE SELLING POINT	Fully hydraulic system
Machinery Test Report	Provided
Video outgoing-inspection	Provided
Warranty of core components	1 Year
Core Components	Pressure vessel, Motor, Other, Bearing, Gear, Pump, Gearbox, Engine, PLC
Application	General Construction Sites

1.The special pouring pump for secondary structure fine stone mortar can realize the transportation of fine stone concrete and
mortar for long-distance high-rise buildings. 2.The distribution valve adopts advanced S-tube valve, which has good sealing
performance and simple and reliable structure.
3.The eye plate (commonly known as wear plate) and floating cutting ring are made of hard alloy, which has good wear resistance,
long service life and convenient replacement. The cutting ring can automatically compensate the gap structure.
4.The machine adopts electric-liquid control mode, with perfect electro-hydraulic overload
protection and instrument display system. It has anti-pump operation function, easy to eliminate blockage fault. The pumping speed
can be adjusted to meet various working conditions.
5.The centralized lubrication system automatically controls the start and stop and running time by the program, effectively
extending the service life of the rotating parts.
6.The electrical components such as the contactor and the push button switch are reliable in operation, the control circuit is
simple, and the electrical box is equipped with a switch for easy operation.
7.The main seals are made of high quality seals to prevent internal and external leakage of the hydraulic system.

Electric control system

The wire remote equipment is convenient for operation far away.Famous brand electronic components are used for our Electric
control system.

Cooling system

The radiator equipment makes the working oil temperature of hydraulic system below 70℃ and makes the machine in normal status.

Mechanical system

Make sure the pumping good and decline the phenomenon of pipe jam, spectacles wear plate and cutting ring are made of high wear
cemented carbide materials. This concrete pump machine could work in lower abrasion and extend the components’ usage life span.
spectacles wear plate could be replaced up 30000cbm.

Double open hydraulic loops

With two pumps, makes the whole hydraulic system much simpler. The reliability of the whole system is also much higher as well as
the components’ life is prolonged greatly. This is convenient for judgeing and removing trouble.
